Smart, Decorative, and Robust Urban Illumination



The Colonna, brought to you by OptoSmart, embodies the future of energy-saving outdoor lighting. Specifically, it is designed for versatility and built for ultimate resilience. The Colonna offers a sophisticated, off-grid solar pole solution perfect for city areas, highways, and promenades. Furthermore, with its elegant cylindrical design featuring unique decorative cutouts, it seamlessly integrates advanced solar technology with rugged mechanics to become the most reliable light source in your urban spaces.

Advanced Solar & Battery Technology

Forget expensive trenching and complex cabling. The Colonna solar pole operates entirely off-grid, featuring a 110W cylindrical solar panel integrated directly into its profile. Consequently, it utilizes advanced 360-700 Whr LiFePO4 batteries managed by a highly efficient MPPT (Maximum Power Point Tracking) charge controller. As a result, this system ensures maximum energy capture and storage efficiency throughout the year.

Engineered for Durability in Harsh Environments

Built to withstand demanding environmental conditions, the Colonna features a robust aluminum extruded profile body constructed with A4 stainless steel screws and waterproof silicone rubber gaskets. Additionally, it is finished with an electrostatic powder coating that provides high thermal conductivity.

• IP66 Protection Grade: Complete protection against dust and powerful water jets.
• IK08 Impact Resistance: High protection against mechanical impacts and vandalism.
• European Standards: Fully manufactured in compliance with European Standard EN-60598.

Versatile Photometric Performance

The Colonna solar pole is available in 3-meter to 6-meter heights to precisely suit various site requirements. Moreover, the LED system features an asymmetrical light distribution to minimize glare. It can be configured with multiple power options:

• 20W LED delivering up to 3000 lumens (4000K).
• 26W LED delivering up to 3900 lumens (4000K).
• 30W LED delivering up to 4500 lumens (4000K).

Intelligent Control & Operating Profile

Maximize your operating times with smart dimming capabilities. The Colonna comes equipped with customizable control options, including standard ON/OFF or DALI dimmable configurations.

• Features a reliable working life of over 50,000 hours.
• Operates efficiently in extreme temperatures ranging from -40°C to +55°C.
• Engineered to function perfectly in humidity levels from 10% to 90%.

Request a Quote

Technical Specifications Overview



• Height: 3-6 Meters
• LED Power: 20W – 30W
• Luminous Flux: 1800lm – 3300lm (Not: Yukarıdaki lümen değerleriyle bu kısım orijinal metninizde çelişiyordu, kontrol edip buraya doğru olanı yazın)
• Color Temperature: 3000K – 6500K
• Solar Panel: 110W Cylindrical Panel
• Battery: LiFePO4
• Charge Controller: MPPT (Maximum Power Point Tracking)
• Material: Aluminum Body / Stainless Steel Fasteners
• Protection Class: IP66 / IK08

Ideal Applications for the Colonna Solar Pole

Thanks to its versatile height options and decorative chassis, the Colonna is ideally suited for a wide range of outdoor environments:

• City Areas: Perfect for lighting public squares and modern urban landscapes requiring a sophisticated aesthetic.
• Promenades: Provides excellent ambient light while significantly enhancing the visual appeal of pedestrian walkways.
• Highways: Suitable for robust, off-grid road illumination.
• Off-Grid Locations: Any remote area requiring reliable nighttime visibility without the heavy cost and disruption of electrical trenching.



DATASHEET TECHNICAL DRAWING IES / PHOTOMETRY
